Triple Axle Hanger Kit for 2" Slipper Springs / APTT6SE

Triple Axle Hanger Kit for 2" Slipper Springs / APTT6SE
Your price: $127.35

Triple Axle Hanger Kit for 2" Slipper Springs / APTT6SE

Hanger Kit Includes:
2 x Front Hangers 3-9/16" Tall / 721584
2 x Rear Hangers 5-1/16" Tall / 721585
4 x Center Hangers 3-3/8" Tall / 721586
2 x Equalizers 12" Overall Length for 2" Slipper Springs / E4541
12 x Shackle Bolts 9/16" x 3-1/2"/ 91635B
12 x Hex Lock Nuts 9/16"/ 916 DLN
4 x Equalizer Bolts, 7/8" x 4-11/16"/ 7845B
4 x Castle Nuts 7/8" For 7845B / 78CN
4 x Cotter Pins 2-1/4" for 7845B / 165649

Additional Information:
If you are using Leaf Springs part number 803T3,

1203T3, 1403T3
A= Distance Between Front and 1st- Center Hangers is: 29"
B= Distance Between Center Hangers is: 33-1/2"
C= Distance Between 2nd-Center and Rear Hangers is: 29"
D= Distance Between U-Bolts is: 33-1/2"
E= Distance Between the Center of the Axle and the Trailer Frame is: 4-3/4"
Axle Diameter: 3"

If you are using Leaf Springs part number E5226
A= Distance Between Front and 1st- Center Hangers is: 29-1/2"
B= Distance Between Center Hangers is: 34"
C= Distance Between 2nd-Center and Rear Hangers is: 29-1/2"
D= Distance Between U-Bolts is: 34"
E= Distance Between the Center of the Axle and the Trailer Frame is: 4-3/4"
Axle Diameter: 3"

If you are using Leaf Springs part number E5115
A= Distance Between Front and 1st- Center Hangers is: 32"
B= Distance Between Center Hangers is: 36-1/2"
C= Distance Between 2nd-Center and Rear Hangers is: 32"
D= Distance Between U-Bolts is: 36-3/4"
E= Distance Between the Center of the Axle and the Trailer Frame is: 4-3/4"
Axle Diameter is: 3"

Used for tandem axle trailers 3500 Lbs through 8000 Lbs using 2" wide slipper leaf springs

Part Number: APTT6SE
